Energy Type Lithium ion 3.2V LiFePO4 Battery 26650 3600mAh for E-bike

  • 1
  • 2

Brand Name : TAC OEM ODM

Model Number : PIFC0904

Certification : MSDS REACH ROHS

Place of Origin : Shenzhen zhuhai

MOQ : 200PCS

Price : USD2.0

Payment Terms : TT, LC, Pay pal etc

Supply Ability : 50000 pack for one week

Delivery Time : 7 days for single cell 15-20 days for battery pack

Packaging Details : Follow UN38.3 Rule

Type : Energy Type Li-ion 3.2V LiFePO4 Battery

Voltage : 3.2V

capacity : 3600mah

circle life : 2000times

Cell Dimension : 26.5* 65.0MM

Warranty : 12 months

Application : E-bike

pvc : blue or OEM

certification : ROHS ul

Contact Now

Energy Type Li-ion 3.2V LiFePO4 Battery 26650 3600mAh for E-bike battery pack

Features for Energy Type Li-ion 3.2V LiFePO4 Battery 26650 3600mAh for E-bike battery pack

  1. Diverse capacity for IFR266503000mAh/3200mAh/3300mAh/3400mAh/3600mAh for your choice
  2. The highest capacity 3600mah for Model IFR26650 cell
  3. Low self discharge can keep 80% original capacity after stock 12 months
  4. Suitable for a wide variety of applications and system designs.
  5. Proven performance in the toughest conditions, combining durability, reliability, and safety
  6. Offers an excellent combination of price-performance.

Application:

  1. Energy Type Li-ion 3.2V LiFePO4 Battery 26650 3200mAh for E-bike battery pack
  2. Portable high power devices
  3. Stationary battery backup systems
  4. Grid stabilization energy storage systems
  5. Commercial truck and bus hybrid electric vehicles (HEVs)

Specification for Energy Type Li-ion 3.2V LiFePO4 Battery 26650 3200mAh for E-bike battery pack

No.

Items

Specifications

1

Charge cut-off voltage

3.65V

2

Nominal voltage

3.2V

3

Minimal capacity

3600mAh @ 0.2C Discharge

4

Nominal capacity

3550mAh @ 0.2C Discharge

5

Charge current

1C

6

Standard charging method

1C CC (constant current) charge to 3.65V, then CV (constant voltage 3.65V) charge till charge current decline to £ 0.05C

7

Charging time

Standard charge: 2.0 hours Ref

8

Max. charge current

2C

9

Max. continue discharge current

10A (Cell skin temperature cannot exceed 80°C)

10

Discharge cut-off voltage

2.0V

11

Operating temperature

Charging: -10°C ~ 45°C

Discharging: -20°C ~ 60°C

(Cell skin temperature cannot exceed 80°C)

12

Storage temperature/humidity

Temperature -10°C ~ +35°C

Humidity 65%±20%RH

(Recommended to store 23 ± 5°C for long term storage)

13

Cell Weight

80.0g±1.0g

14

Cell Dimension

Length: 65.0±0.3 mm

Width: 26.2±0.2 mm

External Packing for Battery cell

put the thin paper board separated the cell one by one to keep the safe

put the anti-tarnish paper on the top and bottom of box .

20pcs for each box , and 6 box for each carton

Energy Type Lithium ion 3.2V LiFePO4 Battery 26650 3600mAh for E-bike

Energy Type Lithium ion 3.2V LiFePO4 Battery 26650 3600mAh for E-bike

Similar Production Pictures:

Energy Type Li-ion 3.2V LiFePO4 Battery 26650 3200mAh for E-bike battery pack

Energy Type Lithium ion 3.2V LiFePO4 Battery 26650 3600mAh for E-bike

Energy Type Lithium ion 3.2V LiFePO4 Battery 26650 3600mAh for E-bike

Energy Type Lithium ion 3.2V LiFePO4 Battery 26650 3600mAh for E-bike

Energy Type Lithium ion 3.2V LiFePO4 Battery 26650 3600mAh for E-bike

More size of for Lifepo4 Cell

Energy Type Lithium ion 3.2V LiFePO4 Battery 26650 3600mAh for E-bike

Most of the model have passed UL1642 UN38.3 certification

Energy Type Lithium ion 3.2V LiFePO4 Battery 26650 3600mAh for E-bike

Energy Type Lithium ion 3.2V LiFePO4 Battery 26650 3600mAh for E-bike
